| 技术参数 | T10 |
| 单元组成 | 1个1.4寸喉口65mm音圈钕磁高音单元 2个10英寸64mm音圈钕磁低音单元 |
| 推荐功率 | 960W |
| 阻抗 | 8Ω |
| 频率响应 | 60Hz-18KHz |
| 标称覆盖角度 | 水平80°,垂直0°-14° 步进为1° |
| 灵敏度(1W/1M) | 105dB |
| 最大声压(1M) | 138dB |
| 接线 | 2×Neutrik NL-4 接线+1、-1 |
| 安装方式 | 吊装或地面摆放 |
| 尺寸(宽x高x深) | 800mmx310mmx460mm |
| 重量 | 27Kg |
| Technical Parameters | T10 |
| Components | 1x1.4”throat exit 65mm voice coil Neodymium HF driver 2x10”64mm voice coil Neodymium LF driver |
| Recommended Amplifier | 960W |
| Nominal Impedance | 8Ω |
| Frequency Response | 60Hz-18KHz |
| Coverage | Hor 80°,Ver0°-14°,1°increment |
| Sensitivity(1W/1M) | 105dB |
| Maximum SPL(1M) | 138dB |
| Connectors | 2×Neutrik NL-4,+1、-1 |
| Installation manner | Flying or ground stacking |
| Dimension (WxHxD) | 800mm x310mm x 460mm |
| Weight | 27Kg |
