| Input/Output | Input Connector | 2×XLR connector |
| Output Power | 2×400W/8Ω(L,R) |
| 1×1400W/8Ω(subwoofer) |
| Output Connector | 2×Phoenix connector:L、R |
| 1×Neutrik 4-pin connector:L1±,R 2± |
| 1×Neutrik 4-pin connector:SUB LINK1± |
| Specipcations | Power Supply | 110-240VAC～50-60Hz |
| Components | 8”51mm voice coil high-power LF driver |
| Audio Processing | DSP inside,with FIR phase correction function |
| Independent data port |
| Input Impedance | 10kQ Balanced |
| 20kQ Unbalanced |
| Frequency Response | 20Hz-20kHz |
| THD | <0.05% |
| Signal/Noise Ratio(dB) | >115dB |
| Damping Factor | >500@1kHz |
| Protect | DC protect | Yes |
| Short-circuit protect | Yes |
| Overheat protect | Yes |
| Dimensions &Weight | Weight | 23.5kg |
| Dimensions(HxWxD) | 538x350×460mm |
